Java[并发]AQS实现源码分析

AQS主要是通过同步队列，独占式同步状态获取、释放和共享式同步状态获取、释放及超时状态获取同步等核心数据结构和模板方法。

一、同步队列（CLH lock queue）的结构

​ 主要由Node内部类来实现构成同步队列的节点，Node本身维护了几种状态：
​ • CANCELLED : 代表线程已经取消
​ • SIGNAL：代表后继节点需要唤醒
​ • CONDITION：代表线程在condition queue中等待某一条件
​ • PROPAGATE：代表后继节点会传播唤醒的操作，在共享模式中使用
​ • INITIAL：初始状态
代码如下：

/** 代表线程已经取消*/
    static final int CANCELLED =  1;
    /** 代表后继节点需要唤醒 */
    static final int SIGNAL    = -1;
    /** 代表线程在condition queue中等待某一条件 */
    static final int CONDITION = -2;
    /**代表后继节点会传播唤醒的操作，在共享模式中使用*/
    static final int PROPAGATE = -3;
//等待状态，上面的几种状态
    volatile int waitStatus;
//前驱节点
    volatile Node prev;
//后继节点
    volatile Node next;
//获取同步状态的线程
    volatile Thread thread;
//等待队列中的后继节点
    Node nextWaiter;

同步队列的结构如下图：

同步队列的出队操作：

private void setHead(Node node) {
        head = node;
        node.thread = null;
        node.prev = null;
}

将头节点移除即可。
同步队列的入队操作：

private Node addWaiter(Node mode) {
        Node node = new Node(Thread.currentThread(), mode);
        // Try the fast path of enq; backup to full enq on failure
        Node pred = tail;
        //优化：只有当compareAndSetTail失败才会进行enq(node)方法循环
        if (pred != null) {
            node.prev = pred;
            if (compareAndSetTail(pred, node)) {
                pred.next = node;
                return node;
            }
        }
        enq(node);
        return node;
    }
private Node enq(final Node node) {
        //进入自旋
        for (;;) {
            Node t = tail;
            if (t == null) { // 没有头节点时，初始化
                Node h = new Node(); //设置一个虚拟的头节点
                h.next = node;
                node.prev = h;
                if (compareAndSetHead(h)) {
                    tail = node;
                    return h;
                }
            }
            else {
                //把尾节点作为插入节点的头节点
                node.prev = t;
                //设置成为尾节点
                if (compareAndSetTail(t, node)) {
                    t.next = node;
                    return t;
                }
            }
        }
}

二、独占式同步状态的获取和释放

独占式同步状态的获取源码分析：

public final void acquire(int arg) {
        //独占式获取，tryAcquire由子类实现不会阻塞线程，如果返回true,则继续
        //如果返回false则加入阻塞队列阻塞线程，并等待前继节点释放锁
        if (!tryAcquire(arg) &&
            acquireQueued(addWaiter(Node.EXCLUSIVE), arg))
            //acquireQueued返回true,说明当前线程被唤醒后获取到锁
            //重置中断状态为true
            selfInterrupt();
}
final boolean acquireQueued(final Node node, int arg) {
        try {
            //等待前继节点释放，自旋re-check
            boolean interrupted = false;
            for (;;) {
                //获取前继节点
                final Node p = node.predecessor();
                //前继节点是head,说明当前节点是next,则尝试获取锁
                if (p == head && tryAcquire(arg)) {
                    //前继节点出列，node成为head
                    setHead(node);
                    p.next = null; // help GC
                    return interrupted;
                }
                //p不是前继节点且tryAcquire获取锁失败，
                //那么阻塞当前线程并等待前继唤醒，阻塞之前再重试一下
                //并设置前继的waitStatus为SIGNAL
                //线程阻塞在parkAndCheckInterrupt方法中，
                //parkAndCheckInterrupt返回可能是前继unpark或线程被中断
                if (shouldParkAfterFailedAcquire(p, node) &&
                    parkAndCheckInterrupt())
                    //说明当前线程是被中断唤醒的，线程被中断会继续走到if判断，也就是忽略中断
                    //除非中断后碰巧acquire成功，那么需要重新设置线程的中断状态selfInterrupted
                    interrupted = true;
            }
        } catch (RuntimeException ex) {
            cancelAcquire(node);
            throw ex;
        }
  }

如果tryAcquire成功则马上返回，失败则acquireQueued加入同步队列，在这过程中线程可能被反复地阻塞和唤醒直到tryAcquire成功，这是因为线程可能被中断。而acquireQueued方法保证忽略中断，只有tryAcquire成功才返回。其中

private static boolean shouldParkAfterFailedAcquire(Node pred, Node node) {
        int ws = pred.waitStatus;
        if (ws == Node.SIGNAL)
            /*
             * This node has already set status asking a release
             * to signal it, so it can safely park
             */
            //前继节点已经设置好unpark了，所以后继可以安全的park
            return true;
        if (ws > 0) {
            /*
             * Predecessor was cancelled. Skip over predecessors and
             * indicate retry.
             */
            //跳过被取消的节点
            do {
                node.prev = pred = pred.prev;
            } while (pred.waitStatus > 0);
            pred.next = node;
        } else {
             //0或者PROPAGATE(CONDITION状态用在ConditionObject,这里不会是CONDITION这个值)
            //waitStatus=0(初始化)或PROPAGATE，会先重试确定无法acquire到再park
            /*
             * waitStatus must be 0 or PROPAGATE. Indicate that we
             * need a signal, but don't park yet. Caller will need to
             * retry to make sure it cannot acquire before parking.
             */
            //更新前继节点状态为SIGNAL
            compareAndSetWaitStatus(pred, ws, Node.SIGNAL);
        }
        return false;
}
private final boolean parkAndCheckInterrupt() {
        //park并且设置线程的interrupted
        LockSupport.park(this);
        return Thread.interrupted();
}

shouldParkAfterFailedAcquire方法的主要作用是：1）确定后继是否需要park；2）略过被取消的节点；3）设置前驱节点的waitStatus为SIGNAL。parkAndCheckInterrupt作用就是阻塞线程，线程被唤醒只可能是被unpark，被中断或伪唤醒。被中断acquire方法返回前会通过selfInterrupted设置interrupted状态，伪唤醒会通过for循环re-check

共享状态的获取流程如下图：

独占式同步状态的释放，源码分析：

public final boolean release(int arg) {
        //tryRelease由子类实现，通过设置state值来达到同步的效果
        if (tryRelease(arg)) {
            Node h = head;
            //waitStatus=0说明是初始化的空队列
            if (h != null && h.waitStatus != 0)
                //唤醒后继节点
                unparkSuccessor(h);
            return true;
        }
        return false;
}
private void unparkSuccessor(Node node) {
        /*

   * If status is negative (i.e., possibly needing signal) try
     clear in anticipation of signalling. It is OK if this

        * fails or if status is changed by waiting thread.

          ​        int ws = node.waitStatus;
          ​        if (ws < 0)
          compareAndSetWaitStatus(node, ws, 0);

        /*
         * Thread to unpark is held in successor, which is normally
         * just the next node.  But if cancelled or apparently null,
         * traverse backwards from tail to find the actual
         * non-cancelled successor.
         */
        Node s = node.next;
        if (s == null || s.waitStatus > 0) {
            s = null;
            for (Node t = tail; t != null && t != node; t = t.prev)
                if (t.waitStatus <= 0)
                    s = t;
        }
        if (s != null)
            LockSupport.unpark(s.thread);

}

释放比较简单，在共享同步变量释放后，最后调用Locksupport.unpark方法使parkAndCheckInterrupt方法返回。

三、共享式同步状态获取和释放

先看共享式同步状态获取的源码实现：

public final void acquireShared(int arg) {
        //如果没有许可则入队等待
        if (tryAcquireShared(arg) < 0)
            doAcquireShared(arg);
}
private void doAcquireShared(int arg) {
        //添加到队列
        final Node node = addWaiter(Node.SHARED);
        try {
            boolean interrupted = false;
            //等待前继释放并传播
            for (;;) {
                final Node p = node.predecessor();
                if (p == head) {
                    //尝试获取许可
                    int r = tryAcquireShared(arg);
                    if (r >= 0) {
                        //获取成功则前继出队，跟独占不同的是会继续向后继节点传播唤醒操作，
                        //保证剩下的线程能尽快地获取剩下的许可。
                        setHeadAndPropagate(node, r);
                        p.next = null; // help GC
                        if (interrupted)
                            selfInterrupt();
                        return;
                    }
                }
                //p不是头节点且获取不到许可
                if (shouldParkAfterFailedAcquire(p, node) &&
                    parkAndCheckInterrupt())
                    interrupted = true;
            }
        } catch (RuntimeException ex) {
            cancelAcquire(node);
            throw ex;
        }
}
private void setHeadAndPropagate(Node node, int propagate) {
        Node h = head; // Record old head for check below
        setHead(node);
        /*
         * Try to signal next queued node if:
         * Propagation was indicated by caller,
         * or was recorded (as h.waitStatus) by a previous operation
         * (note: this uses sign-check of waitStatus because
         * PROPAGATE status may transition to SIGNAL.)
         * and
         * The next node is waiting in shared mode,
         * or we don't know, because it appears null
         *
         * The conservatism in both of these checks may cause
         * unnecessary wake-ups, but only when there are multiple
         * racing acquires/releases, so most need signals now or soon
         * anyway.
         */
        /**
         * 尝试唤醒后继节点，propagate>0说明许可还有能继续被线程acquires
         * 或者之前的head被设置为PROPAGATE(PROPAGATE或以转换为SIGNAL)
         * 或者为null。检查有些保守，在多竞争时，可能出现不必要的唤醒
         */
        if (propagate > 0 || h == null || h.waitStatus < 0) {
            Node s = node.next;
            if (s == null || s.isShared())
                //唤醒后继节点
                doReleaseShared();
        }
}

doAcquiredShare方法与独占式很像，唯一区别在setHeadAndPropagate方法，这个方法将Node设置为Head后，如果发现还有许可，会继续释放给后面的节点，后面的节点会把这个动作传播下去。

共享式同步状态释放：

public final boolean releaseShared(int arg) {
        if (tryReleaseShared(arg)) {
            doReleaseShared();
            return true;
        }
        return false;
}
private void doReleaseShared() {
        /*
         * Ensure that a release propagates, even if there are other
         * in-progress acquires/releases. This proceeds in the usual
         * way of trying to unparkSuccessor of head if it needs
         * signal. But if it does not, status is set to PROPAGATE to
         * ensure that upon release, propagation continues.
         * Additionally, we must loop in case a new node is added
         * while we are doing this. Also, unlike other uses of
         * unparkSuccessor, we need to know if CAS to reset status
         * fails, if so rechecking.
         */
        for (;;) {
            Node h = head;
            //队列不为空且有后继节点
            if (h != null && h != tail) {
                int ws = h.waitStatus;
                //不管共享还是独占模式，只要节点waitStatus为SIGNAL状态都唤醒
                if (ws == Node.SIGNAL) {
                    //将waitStatus设置为0
                    if (!compareAndSetWaitStatus(h, Node.SIGNAL, 0))
                        continue; // loop to recheck cases
                    //唤醒后继节点
                    unparkSuccessor(h);
                }
                else if (ws == 0 &&
                         !compareAndSetWaitStatus(h, 0, Node.PROPAGATE))
                    continue; // loop on failed CAS
            }
            //如果循环过程中head节点被修改了则重试
            if (h == head) // loop if head changed
                break;
        }
}

四、独占式超时获取同步状态

独占式超时获取同步状态的代码如下：

private boolean doAcquireNanos(int arg, long nanosTimeout)
        throws InterruptedException {
        long lastTime = System.nanoTime();
        final Node node = addWaiter(Node.EXCLUSIVE);
        try {
            for (;;) {
                final Node p = node.predecessor();
                if (p == head && tryAcquire(arg)) {
                    setHead(node);
                    p.next = null; // help GC
                    return true;
                }
                if (nanosTimeout <= 0) {
                    cancelAcquire(node);
                    return false;
                }
                if (nanosTimeout > spinForTimeoutThreshold &&
                    shouldParkAfterFailedAcquire(p, node))
                    LockSupport.parkNanos(this, nanosTimeout);
                long now = System.nanoTime();
                //计算时间，当前now减去睡眠之前的时间lastTime得到已经睡眠的时间delta,
                //然后被原有超时时间nanosTimeout减去，得到了还应该睡眠的时间
                nanosTimeout -= now - lastTime;
                lastTime = now;
                if (Thread.interrupted())
                    break;
            }
        } catch (RuntimeException ex) {
            cancelAcquire(node);
            throw ex;
        }
        // Arrive here only if interrupted
        cancelAcquire(node);
        throw new InterruptedException();
}

该方法在自旋过程中，获取前驱节点时，如果成功则返回，这个和独占式是一样的，不同的地方在失败处理上。如果当前线程获取同步状态失败，则判断是否超时（当nanosTimeout 小于等于0时表示已经超时），如果没有超时，重新计划超时时间nanosTimeout ，然后当前线程等待nanosTimeout 纳秒（当已到设置的超时时间，线程会从LockSupport.parkNanos(this, nanosTimeout)方法返回），
如果nanosTimeout 小于等于spinForTimeoutThreshold （1000纳秒）时，将不会使该线程进行超时等待，而是进入快速自旋过程。
独占式超时获取同步状态的流程如下图：
